Samarium Cobalt Rectangular Magnet - 13/16 in. x 1/4 in. x 1/16 in. thick - 1.89lbs Pull
*Measurements have been rounded to the nearest fraction inch - please check the product description for specific measurements.*
High-operating temperature, thin, rectangular samarium cobalt (Sm2Co17) magnets, capable of operating in temperatures up to 300 degrees Celsius with superb resistance to corrosion.
Please fill out the following form to Ask a Question about this product:
Please fill out the following form to Tell a Friend about this product:
- 20mm x 6mm x 1.5mm thick.
- 0.79 in. x 0.24 in. x 0.06 in. thick.
- +/-0.1mm (0.0004 in.) tolerance.
- Each magnet's north and south pole are on opposite 20mm (0.79 in.) x 6mm (0.24 in.) faces.
- Each magnet can support a steel weight of up to 0.86kg (1.9lbs) vertically from the magnetic face when in flush contact with a mild steel surface of equal thickness.
- 572 degrees Fahrenheit maximum operating temperature.
- Resistant to demagnetisation and corrosion without any extra coating.
Samarium cobalt is a type of rare-earth magnet that has the ability to withstand and operate in high temperatures, however they are not as powerful as super-strong Neodymium magnets. Because of their high maximum operating temperature they are commonly used in applications such as motors and electric motors, turbo machinery and sensors. They also have many uses in engineering and manufacturing where size and strength is important, in fact two samarium cobalt magnets will attract each other with twice the force that they attract steel.
