N42 Neodymium Diametrically Magnetised Rod Magnet - 1/8 in. dia x 1/2 in. thick
Code: F800DM-30
*Measurements have been rounded to the nearest fraction inch - please check the product description for specific measurements.*
High-performance, diametrically magnetised Neodymium (N42) small, rod magnet. These diametrically magnetised magnets have their north and south pole on opposite curved sides, cutting the flat surface in half.
Choose Pack Size:
$10.92
In Stock
NEXT DAY DELIVERY
available to the uk
STANDARD DELIVERY
From £2.25 + VAT.
100% SECURE
Online ordering.
NEXT DAY DELIVERY
available to the uk
STANDARD DELIVERY
From £2.25 + VAT.
100% SECURE
Online ordering.
Ask A Question
Please fill out the following form to Ask a Question about this product:
Email A Friend
Please fill out the following form to Tell a Friend about this product:
- 3mm x 12mm.
- 0.12 in. x 0.47 in.
- +/-0.1mm (0.004 in.) tolerance.
- Excellent resistance to demagnetisation.
- Triple coated
- Unusually, diametrically magnetised magnets are not designed to hold the maximum possible weight for the size of the magnet but instead are used to provide rotational movement. A diametrically magnetised magnet is magnetised across its diameter so that the north pole in on one curved side and the south pole is on the opposite curved side. Diametrically magnetised magnets are used on the end of shafts to provide drive. They can also be used to produce a magnetic rack and pinion system by using a line of north and south in alternating polarities. It is also possible to use diametrically magnetised magnets for reed switch applications.
